CAR OBD2 SCANNER BLUETOOTH

Specifications:

• Application: Compatible with 12 V gasoline and diesel vehicles
• Supported devices: iOS and Android
• Operating voltage: 12 V DC (9–16 V)
• Working current: ≤50 mA
• Bluetooth version: 5.2
• Transmission distance: Up to 10 m (open, interference-free environment)
• Operating temperature: –20 °C to 60 °C
• Storage temperature: –30 °C to 70 °C
• Language:
  Default is English
  (automatically follows the phone’s language settings)

Protocols:

1. SAE J1850 PWM(41.6Kbaud)
2. SAE J1850 VPW(10.4Kbaud)
3. ISO9141-2(5 baud init,10.4Kbaud)
4. ISO14230-4 KWP(5 baud init,10.4 Kbaud)
5. ISO14230-4 KWP(fast init,10.4 Kbaud)
6. ISO15765-4 CAN(11bit ID,500 Kbaud)
7. ISO15765-4 CAN(29bit ID,500 Kbaud)
8. ISO15765-4 CAN(11bit ID,250 Kbaud)
9. ISO15765-4 CAN(29bit ID,250 Kbaud)

Functions:

• Read trouble codes (DTCs)
• Erase codes / clear Check Engine Light
• View vehicle information
• DTC lookup for detailed explanations
• Generate OBD diagnostic reports
• Live dashboard and real-time data monitoring
• O₂ sensor testing
• Freeze frame data capture
• I/M readiness check (emissions test readiness)
• On-board monitoring
• EVAP system test (Mode $08)
